Basic Info.
Certification
RoHS, ISO9001, ASTM, JIS, GB, EN
Technique
Cold Drawn
Grade
3000 Series
Temper
O - H112
Surface Treatment
Mill Finish
Alloy
Alloy
Width
914mm, 1000mm, 1219mm
Length
30m, 50m, or as Requested
Quality Control
ISO 9001
Polysurlyn Thickness
0.076mm(3 Mil)
Polysurlyn Brand
DuPont
Kraft Paper Thickness
0.14-0.16mm
Delivery Time
35 Days
Pencil Hardness
H12/H14/H16/ H24/ H26
Moisture Barrier
Polysurlyn, Craft Paper
Transport Package
Pallet Packing
Specification
0.4-1.2mm
Trademark
EcoIn Insulation
Origin
China
HS Code
7606125900
Production Capacity
20000 Tons Per Year
Product Description
Product Description
Smooth aluminium jacketing with a factory bonded moisture barrier
There are 8 series of aluminum alloy, from 1xxx to 8xxxx. Most common used alloy for insulation is 1100, 1060, 3003, 3105 and5005. 3003 is better in anti-rust performance than 1060. Aluminum jacketing is available in Smooth, Stucco Embossed, Corrugated(cross-crimped) finishes, with or without moisture barrier (craft paper and poly surlyn)
Standard Sizes
| Thickness (inch) | Thickness (mm) | Width (mm) | Length (m) | Suggested Application |
| 0.016 | 0.4 | 914, 1000, 1219 | 30, 60, 90, coil or sheet | OD below 36"(914mm) insulated lines |
| 0.020 | 0.5 | 914, 1000, 1219 | 30, 60, 90, coil or sheet | OD below 36"(914mm) insulated lines |
| 0.024 | 0.6 | 914, 1000, 1219 | 30, 60, 90, coil or sheet | OD 36"-8′ (914mm-2.43m) insulated lines&equipment |
| 0.032 | 0.8 | 914, 1000, 1219 | 30, 60, 90, coil or sheet | special applications where extra thickness and protection is required, such as fabricated tank head covers and other special fabrications |
| 0.040 | 1.0 | 914, 1000, 1219 | 30, 60, 90, coil or sheet | special applications where heavy mechanical is required |
| 0.050 | 1.2 | 914, 1000, 1219 | 30, 60, 90, coil or sheet | flat ducts or precipitators. Also recommended for areas subject to high wind conditions |
Product Paramenters
| item | value |
| Model Number | 1060/3003 insulation jacketing with MB |
| Application | Insulation jacketing |
| Width | 618mm-1800mm |
| Alloy Or Not | Is Alloy |
| Grade | 3000 Series |
| Surface Treatment | Embossed |
| Temper | O - H112 |
| Tolerance | ±1% |
| Processing Service | Bending, Decoiling, Welding, Punching, Cutting |
| Delivery Time | 46-60 days |
| Product name | Aluminum cladding coil with moisture barrier |
| Application | Insulation Jacketing |
| Certification | ISO, BV |
| Standard | GB/T3880, ASTM B209, ASTM C1729 |
| Material | Aluminum Alloy Metal |
| Moisture barrier | polysurlyn, craft paper |
| Surface tread | Plain, Stucco Embossed, corrugated |
| Color | Silvery, Or colored |
| Alloy | 1050/1060/1100/3003/5052 |
| Pencil hardness | H14, H18, H24,t6 |
Chemical Composition
| Alloy | Si | Fe | Cu | Mn | Zn | Mg | Ti | Cr | Other Elements | Al | ||||
| Each | Total | |||||||||||||
| 1060 | 0.25 | 0.35 | 0.05 | 0.03 | 0.05 | 0.03 | 0.03 | - | 0.03 | 99.6min | ||||
| 1100 | Si+Fe=0.95 | 0.05-0.20 | 0.05 | 0.10 | - | - | - | 0.05 | 0.15 | 99.0min | ||||
| 3003 | 0.6 | 0.7 | 0.05-0.20 | 1.0-1.50 | 0.10 | - | - | - | 0.05 | 0.15 | reminder | |||
| 3105 | 0.6 | 0.7 | 0.30 | 0.30-0.80 | 0.40 | 0.20-0.80 | 0.10 | 0.20 | 0.05 | 0.15 | reminder | |||
| 5005 | 0.3 | 0.7 | 0.20 | 0.20 | 0.25 | 0.50-1.10 | - | - | 0.05 | 0.15 | reminder | |||
Application
- Aluminum Jacketing is recommended for HVAC, Insulated Piping, Tanks & vessels less than 8 feet in diameter.
- Deep corrugated sheets are recommended for diameters greater than 8 feet.
- Chemical Plants & Refineries: Distillation columns, tank farms, fractionation units, cokers and ethylene production units.
- Paper Mills: Chemical storage tanks, breechings and ducts.
- Steel Mills: Pickle acid tanks, oxygen production units, fuel oil and tar storage tanks.
- Miscellaneous: Power station, Food processing plants, LPG storage units, LNG storage units, sewage and waste water treatment plants.
